วาล์วผีเสื้อเวเฟอร์: หลักการทำงาน ประเภท ข้อดี และการแนะนำการใช้งาน
- วาล์วเดลโก้
Wafer butterfly valve is a common industrial pipeline valve, mainly used to control the fluid medium in the pipeline. In this article, วาล์วเดลโก้ introduces the types, advantages and applications of wafer butterfly valve to help you better understand wafer butterfly valve.
What is a wafer type butterfly valve?
Wafer butterfly valve is a kind of butterfly valve, most of the wafer butterfly valves are designed with four holes which are aligned with the connected pipes. Wafer butterfly valves are designed to be clamped between two flanges in pipework. Most wafer butterfly valves are flange compliant. The rubber seat forms a very strong seal between the valve and the flange connection.
Working Principle of Wafer butterfly valve
Wafer butterfly valves are right-angle rotary valves that are opened or closed by rotating the disc 90 degrees. Actuated and manual valves use the same principle of operation. When fluid flow needs to be initiated, the operator rotates the handwheel 90 degrees counterclockwise. The rotation of the handle causes the valve stem and disc to follow suit. This causes the disc to align with the direction of fluid flow, which opens the valve to allow fluid to pass through. To close the valve, simply rotate the handwheel clockwise, which causes the disk to be oriented perpendicular to the pipeline, completely blocking fluid from passing through the valve. When the disk is rotated less than 90 degrees, the butterfly valve acts as a throttle.
Types of wafer butterfly valve
Manual wafer butterfly valve
Manual Wafer butterfly valve use a handwheel or handle as the control device, and the operator applies force to open or close the valve. Compared to automatic butterfly valves, this type of valve is more cost-effective. Manual butterfly valves are used in locations where electricity or other power sources are not available or are costly. Although manual wafer butterfly valve are inexpensive and easy to operate, operators need to be aware of the risks involved when handling leaky or hazardous fluids. In situations where the valve needs to be opened and closed frequently and high torque needs to be applied, the operator may become fatigued.
Motorized wafer butterfly valve
Motorized wafer butterfly valve are a type of butterfly valve that is operated by a motorized actuator. DELCO Valve’s actuators are equipped with an automated system that efficiently determines when the butterfly plate closes or opens the flow of fluid. Motorized wafer butterfly valves are widely used in various industries, however, they are more expensive compared to manual wafer butterfly valve. In addition, motorized wafer butterfly valves are relatively expensive to maintain.
Pneumatic wafer butterfly valve
Pneumatic wafer butterfly valve is a type of butterfly valve that is operated by pneumatic actuator. A pneumatic actuator is a device that converts the energy of compressed air into the mechanical energy required to operate the valve. Pneumatic wafer butterfly valves generate pressure by utilizing compressed air into the chamber. Once the pressure exceeds a specific level of atmospheric pressure outside the chamber, the valve automatically opens or closes. Pneumatic wafer butterfly valves have a wide range of applications and can be used in a variety of industrial scenarios.
Advantages of wafer butterfly valves
- Wafer butterfly valve can be automatic or manual.
- The use of quarter turns to open and close the fluid flow allows these valves to operate quickly.
- Wafer butterfly valves come in a simple and compact design.
- Wafer butterfly valve are small and lightweight.
- Wafer butterfly valves require little installation space
- Wafer butterfly valves are easy to clean, install and maintain.
- The simple design of the wafer butterfly valve makes it versatile and therefore suitable for use in a wide range of industries.
- Wafer butterfly valves can be used for bidirectional or unidirectional fluid flow.
- Wafer butterfly valves are resistant to corrosion and abrasion.
- Wafer butterfly valves can be used in slurry and sludge applications.
Application of wafer butterfly valves
- Wafer butterfly valves are used in fire fighting systems.
- Wafer butterfly valves are used in the manufacture of chemicals.
- Wafer butterfly valves are used for municipal wastewater treatment and water purification.
- Wafer butterfly valves are used in heating, ventilation and air conditioning systems.
- Wafer butterfly valves are used in food and beverage processing.
- Wafer butterfly valves are used in oil refineries.
- Wafer butterfly valves for mining applications.
- Wafer butterfly valves are used in the pharmaceutical industry.
