Injap Glob Pneumatik DELCO J641W/H untuk Pengawalan Ketepatan Tinggi dan Pemotongan Tekanan Tinggi

✅ Precise Flow Regulation: Utilizing a conical or flat seal valve core and linear movement, the pneumatic globe valve is excellent for throttling and modulating fluid flow rates. When equipped with a positioner, it can achieve high-precision control via a 4-20mA signal, with fast response speeds crucial for dynamic automation systems.

✅ High Pressure Capability: Built to handle nominal pressures ranging from PN1.6 up to PN6.4 (1.6 MPato 6.4 MPa), the design is inherently suited for high-differential pressure services where tight shutoff and reliable performance under stress are required.

✅ Fail-Safe Automatic Reset: The pneumatic actuator is typically equipped with a compressed spring. Upon loss of air source or power, the spring drives the valve core to automatically reset to a predetermined safe position (Terbuka sepenuhnya atau tertutup sepenuhnya), Menjamin keselamatan sistem.

✅ Versatile Material and Corrosion Resistance: Standard body materials include Stainless Steel (304, 316) dan WCB, offering strength and resistance to general industrial fluids. Fluorine-lined options are also available for applications involving strong acids and alkalis.

✅ Straight-Through and Angle Body Options: The valve body is commonly available in Straight-Through or Angle patterns. Note that the S-shaped flow channel design, while effective, results in relatively higher flow resistance compared to ball or gate valves.
